Model		BetaScan S1	BetaScan Elite S1
Scanning Mode	High-speed scanning	26 crossed blue laser lines	50 crossed blue laser lines
	Precision scanning	17 parallel blue laser lines	17 parallel blue laser lines
	Deep hole scanning	1 single blue laser line	1 single blue laser line
Accuracy		up to 0.020mm
Measurement rate		6,000,000 measurements/s	8,300,000 measurements/s
Scanning area		up to 650mm×550mm
Laser class		Class II (Eye safe)
Resolution		up to 0.01mm
Volumetric accuracy		0.015mm+0.035mm/m 0.015mm+0.025mm/m (working with photogrammetric scale bar)
Working distance		300mm (200mm fine mode)
Depth of field		550mm
Output formats		stl, ply, obj, txt etc.
Operating temperature		-10°C to 40°C
Product dimensions		L×W×H：340×145×70mm
Product weight		1.15kg
Interface type		USB 3.0
Minimum computer requirements		OS: Windows 10 or later (64-bit required) GPU: NVIDIA GTX/RTX series (e.g., RTX 4060 or higher) VRAM: 8 GB or more CPU: Intel Core i7-13700H or better RAM: 32 GB or higher
